Original Article
Comparison of Results of Tension Band Wire and Hook Plate in the Treatment of Unstable Fractures of the Distal Clavicle: Chul-Hyun Park, M.D., Oog-Jin Shon, M.D., Jae-Sung Seo, M.D.; Journal of the Korean Fracture Society 2011;24(1):55-59.
DOI: https://doi.org/10.12671/jkfs.2011.24.1.55
Published online: January 19, 2011

Department of Orthopedic Surgery, Yeungnam University Hospital, Daegu, Korea.

Address reprint requests to: Oog-Jin Shon, M.D. Department of Orthopedic Surgery, Yeungnam University Hospital, 317-1, Daemyeong-dong, Nam-gu, Daegu 705-717, Korea. Tel: 82-53-620-3640·Fax: 82-53-628-4020, ossoj@med.yu.ac.kr

• Received: August 11, 2010 • Revised: September 13, 2010 • Accepted: October 23, 2010

112 Views
0 Download
1 Crossref

prev next

Full Article

Download PDF

Abstract
REFERENCES

Abstract

Purpose
To compare the clinical and radiological outcomes of two surgical methods with tension band wire and Hook plate for unstable distal clavicle fractures.
Materials and Methods
Thirty patients with type II distal clavicle fractures were evaluated, who were operated with tension band wire (Group I) and Hook plate (Group II) fixation, from June 2005 to June 2009, and could be followed-up for more than 1 year after operation. The reduction and union were evaluated by the immediate post-operative and final radiographs. The functional outcome was evaluated by Kona's system and Constant-Murley scoring system.
Results
All 30 cases showed bony union. By Kona's functional evaluation, there were 16 cases with excellent and good results in Group I and 14 cases in Group II. The average Constant score was 88.3 (71~100) in Group I and 89.6 (72~100) in Group II, but there was no significant difference in both groups. As complications, there were 2 case with subacromial impingement, and 1 case showed subacromial erosion. There was no K-wire migration, deep infection and acromioclavicular joint arthritis.
Conclusion
Tension band and Hook plate fixation technique gave satisfactory clinical and radiological results in patients with type II distal clavicle fractures. These results suggest that tension band wire and Hook plate fixation technique seems to be an effective method for type II distal clavicle fracture. But we think thal early removal of plate is necessary due to risks for subacromial impingement and erosion in Hook plate fixation.
Key words: Distal clavicle, Fracture, Neer type II, Tension band fixation, Hook plate fixation

REFERENCES

1. Ahn BW, Yoon JH, Kim CK, et al. Internal fixation of clavicle lateral and fracture with mini T-plate. J Korean Fract Soc, 2005;18:410-414.Article
2. Balser D. Eine neue Moethode zur operativen Behandlung der akromioklavikularen Luxation. Chir Prax, 1976;24:275-281.
3. Chun JM, Kim SY, Lee KW, Shin SJ, Kim EG. Modified tenson band fixation for unstable fracture of the distal clavicle. J Korean Orthop Assoc, 2002;37:416-420.Article PDF
4. Constant CR, Murley AH. A clinical method of functional assessment of the shoulder. Clin Orthop Relat Res, 1987;214:160-164.Article
5. Eberle C, Fodor P, Metzger U. Hook plate (so-called Balser plate) or tension banding with the Bosworth screw in complete acromioclavicular dislocation and clavicular fracture. Z Unfallchir Versicherungsmed, 1992;85:134-139.
6. Edwards DJ, Kavanagh TG, Flannery MC. Fractures of the distal clavicle: a case for fixation. Injury, 1992;23:44-46.
7. Flinkkilä T, Ristiniemi J, Hyvönen P, Hämäläinen M. Surgical treatment of unstable fractures of the distal clavicle: a comparative study of Kirschner wire and clavicular hook plate fixation. Acta Orthop Scand, 2002;73:50-53.
8. Flinkkilä T, Ristiniemi J, Lakovaara M, Hyvönen P, Leppilahti J. Hook-plate fixation of unstable lateral clavicle fractures: a report on 63 patients. Acta Orthop, 2006;77:644-649.
9. Hackenbruch W, Regazzoni P, Schwyzer K. Surgical treatment of lateral clavicular fracture with the "clavicular hooked plate". Z Unfallchir Versicherungsmed, 1994;87:145-152.
10. Kao FC, Chao EK, Chen CH, Yu SW, Chen CY, Yen CY. Treatment of distal clavicle fracture using Kirschner wires and tension-band wires. J Trauma, 2001;51:522-525.
11. Kashii M, Inui H, Yamamoto K. Surgical treatment of distal clavicle fractures using the clavicular hook plate. Clin Orthop Relat Res, 2006;447:158-164.
12. Kona J, Bosse MJ, Staeheli JW, Rosseau RL. Type II distal clavicle fractures: a retrospective review of surgical treatment. J Orthop Trauma, 1990;4:115-120.
13. Meda PV, Machani B, Sinopidis C, Braithwaite I, Brownson P, Frostick SP. Clavicular hook plate for lateral end fractures:- a prospective study. Injury, 2006;37:277-283.
14. Mizue F, Shirai Y, Ito H. Surgical treatment of comminuted fractures of the distal clavicle using Wolter clavicular plates. J Nihon Med Sch, 2000;67:32-34.
15. Muramatsu K, Shigetomi M, Matsunaga T, Murata Y, Taguchi T. Use of the AO hook-plate for treatment of unstable fractures of the distal clavicle. Arch Orthop Trauma Surg, 2007;127:191-194.
16. Neer CS 2nd. Fractures of the distal third of the clavicle. Clin Orthop Relat Res, 1968;58:43-50.
17. Neviaser RJ, Neviaser JS, Neviaser TJ, Neviaser JS. A simple technique for internal fixation of the clavicle. A long term evaluation. Clin Orthop Relat Res, 1975;109:103-107.
18. Nordqvist A, Petersson C, Redlund-Johnell I. The natural course of lateral clavicle fracture 15 (11-21) year follow-up of 110 cases. Acta Orthop Scand, 1993;64:87-91.
19. Park JY, Seo JB, Kim MH, Yu JW. Tension band fixation for type II fracture of the distal clavicle. J Korean Fract Soc, 2005;18:421-425.
20. Renger RJ, Roukema GR, Reurings JC, Raams PM, Font J, Verleisdonk EJ. The clavicle hook plate for Neer type II lateral clavicle fractures. J Orthop Trauma, 2009;23:570-574.
21. Rowe CR. An atlas of anatomy and treatment of midclavicular fractures. Clin Orthop Relat Res, 1968;58:29-42.
22. Zenni EJ Jr, Krieg JK, Rosen MJ. Open reduction and internal fixation of clavicular fractures. J Bone Joint Surg Am, 1981;63:147-151.

Fig. 1

(A) Radiograph of 56-year-old male shows Neer type II distal clavicle fracture.

(B) Satisfactory reduction and tension band wire fixation without acromioclavicular joint injury were seen in immediate postoperative radiograph.

(C, D) Bony union was seen in postperative 6 months radiograph and there were no K-wire migration and acromioclavicular joint arthritis.

Fig. 2

(A) Radiograph of 57-year-old male shows Neer type II distal clavicle fracture.

(B) Satisfactory reduction and Hook plate fixation were seen in immediate postoperative radiograph.

(C) Proximal screw loosening & plate migration were seen in postperative 6 months radiograph and there was subacromial impingment symptom.

(D) After the operation of Hook plate removal, radiographs show good bony union and impingment symptom was disappeared.
