Analysis of the Fixation Failure in Intertrochanteric Hip Fractures Treated with Hip Nailing: Jun-Dong Chang, M.D., Ph.D., Tae-Young Kim, M.D., Ji-Hyo Hwang, M.D., Ph.D., Seul-Ki Min, M.D., Je-Hyun Yoo, M.D., Ph.D.; Journal of the Korean Fracture Society 2012;25(3):169-176.
DOI: https://doi.org/10.12671/jkfs.2012.25.3.169
Published online: July 16, 2012

Department of Orthopedic Surgery, Hallym University College of Medicine, Seoul, Korea.

Address reprint requests to: Je-Hyun Yoo, M.D., Ph.D. Department of Orthopedic Surgery, Hallym University Sacred Heart Hospital, Hallym University College of Medicine, 22, Gwanpyeong-ro 170-gil, Dongan-gu, Anyang 431-070, Korea. Tel: 82-31-380-3770, Fax: 82-31-382-1814, oships@hallym.ac.kr

• Received: July 21, 2011 • Revised: November 25, 2011 • Accepted: May 20, 2012

113 Views
0 Download
1 Crossref

Full Article

Download PDF

Abstract
REFERENCES

Abstract

Purpose
To analyze the patterns of and risk factors for fixation failure after hip nailing in intertrochanteric (IT) hip fractures.
Materials and Methods
Fourteen patients who sustained a fixation failure after hip nailing for IT hip fractures were enrolled in this study. The mean age at the index surgery was 74.5 years and the mean time to the fixation failure was 6.6 weeks. All of the serial radiographs up to the fixation failure and pre-operative 3-D computed tomography were analyzed.
Results
According to AO classification, there were 7 stable fractures and 7 unstable ones. Of the total of 14 cases, 10 showed a comminution of the greater trochanter tip and incomplete anatomical reduction of the medial and anterior cortex at the fracture site. Of the 10 cases with appropriate position of the lag screw within the femoral head, 9 showed a high pertrochanteric fracture (HPF) pattern. The mechanism of the fixation failure was rotation of the femoral head in 7 of 9 cases with HPF and varus collapse of the proximal fragment in 4 of the other 5 cases.
Conclusion
The HPF pattern, the comminution of the greater trochanter tip, and incomplete reduction of the medial and anterior cortex may be additional risk factors of fixation failure after treating IT hip fractures with hip nailing in.
Key words: Femur, Intertrochanteric fracture, Hip nail, Fixation failure

REFERENCES

1. Baumgaertner MR, Curtin SL, Lindskog DM. Intramedullary versus extramedullary fixation for the treatment of intertrochanteric hip fractures. Clin Orthop Relat Res, 1998;(348):87-94.Article
2. Bojan A, Taglang G, Beimel C, Jonsson A, Schnettler R. A retrospective analysis of cut out complication in 3066 patients treated with Gamma nails. J Orthop Trauma, 2004;18:S21.
3. Boriani S, Bettelli G, Zmerly H, et al. Results of the multicentric Italian experience on the Gamma nail: a report on 648 cases. Orthopedics, 1991;14:1307-1314.Article
4. Bridle SH, Patel AD, Bircher M, Calvert PT. Fixation of intertrochanteric fractures of the femur. A randomised prospective comparison of the gamma nail and the dynamic hip screw. J Bone Joint Surg Br, 1991;73:330-334.Article PDF
5. Brink PR, Bolhuis RJ, Runne WC, De Vries AC. Low nail-plate fixation and early weight-bearing ambulation for stable trochanteric fractures. J Trauma, 1987;27:491-495.
6. Butt MS, Krikler SJ, Nafie S, Ali MS. Comparison of dynamic hip screw and gamma nail: a prospective, randomized, controlled trial. Injury, 1995;26:615-618.Article
7. Carr JB. The anterior and medial reduction of intertrochanteric fractures: a simple method to obtain a stable reduction. J Orthop Trauma, 2007;21:485-489.Article
8. Davis J, Harris MB, Duval M, D'Ambrosia R. Pertrochanteric fractures treated with the Gamma nail: technique and report of early results. Orthopedics, 1991;14:939-942.Article
9. Davis TR, Sher JL, Horsman A, Simpson M, Porter BB, Checketts RG. Intertrochanteric femoral fractures. Mechanical failure after internal fixation. J Bone Joint Surg Br, 1990;72:26-31.
10. Den Hartog BD, Bartal E, Cooke F. Treatment of the unstable intertrochanteric fracture. Effect of the placement of the screw, its angle of insertion, and osteotomy. J Bone Joint Surg Am, 1991;73:726-733.
11. Doherty JH Jr, Lyden JP. Intertrochanteric fractures of the hip treated with the hip compression screw: analysis of problems. Clin Orthop Relat Res, 1979;(141):184-187.
12. Fogagnolo F, Kfuri M Jr, Paccola CAJ. Intramedullary fixation of pertrochanteric fractures with the short AO-ASIF proximal femoral nail. Arch Orthop Trauma Surg, 2004;124:31-37.Article PDF
13. Geller JA, Saifi C, Morrison TA, Macaulay W. Tip-apex distance of intramedullary devices as a predictor of cut-out failure in the treatment of peritrochanteric elderly hip fractures. Int Orthop, 2010;34:719-722.
14. Goldhagen PR, O'Connor DR, Schwarze D, Schwartz E. A prospective comparative study of the compression hip screw and the gamma nail. J Orthop Trauma, 1994;8:367-372.
15. Halder SC. The Gamma nail for peritrochanteric fractures. J Bone Joint Surg Br, 1992;74:340-344.
16. Johnell O, Kanis JA. An estimate of the worldwide prevalence, mortality and disability associated with hip fracture. Osteoporos Int, 2004;15:897-902.
17. Kawaguchi S, Sawada K, Nabeta Y. Cutting-out of the lag screw after internal fixation with the Asiatic gamma nail. Injury, 1998;29:47-53.
18. Kim WY, Han CH, Park JI, Kim JY. Failure of intertrochanteric fracture fixation with a dynamic hip screw in relation to pre-operative fracture stability and osteoporosis. Int Orthop, 2001;25:360-362.
19. Kyle RF, Gustilo RB, Premer RF. Analysis of six hundred and twenty-two intertrochanteric hip fractures. J Bone Joint Surg Am, 1979;61:216-221.
20. Larsson S, Friberg S, Hansson LI. Trochanteric fractures. Influence of reduction and implant position on impaction and complications. Clin Orthop Relat Res, 1990;(259):130-139.
21. Laskin RS, Gruber MA, Zimmerman AJ. Intertrochanteric fractures of the hip in the elderly: a retrospective analysis of 236 cases. Clin Orthop Relat Res, 1979;(141):188-195.
22. Leung KS, So WS, Shen WY, Hui PW. Gamma nails and dynamic hip screws for peritrochanteric fractures. A randomised prospective study in elderly patients. J Bone Joint Surg Br, 1992;74:345-351.
23. Lindsey RW, Teal P, Probe RA, Rhoads D, Davenport S, Schauder K. Early experience with the gamma interlocking nail for peritrochanteric fractures of the proximal femur. J Trauma, 1991;31:1649-1658.
24. Liu M, Yang Z, Pei F, Huang F, Chen S, Xiang Z. A meta-analysis of the Gamma nail and dynamic hip screw in treating peritrochanteric fractures. Int Orthop, 2010;34:323-328.
25. Mahomed N, Harrington I, Kellam J, Maistrelli G, Hearn T, Vroemen J. Biomechanical analysis of the Gamma nail and sliding hip screw. Clin Orthop Relat Res, 1994;(304):280-288.
26. Mainds CC, Newman RJ. Implant failures in patients with proximal fractures of the femur treated with a sliding screw device. Injury, 1989;20:98-100.
27. Mulholland RC, Gunn DR. Sliding screw plate fixation of intertrochanteric femoral fractures. J Trauma, 1972;12:581-591.
28. Nishiura T, Nozawa M, Morio H. The new technique of precise insertion of lag screw in an operative treatment of trochanteric femoral fractures with a short intramedullary nail. Injury, 2009;40:1077-1083.
29. Parker MJ. Cutting-out of the dynamic hip screw related to its position. J Bone Joint Surg Br, 1992;74:625.
30. Radford PJ, Needoff M, Webb JK. A prospective randomised comparison of the dynamic hip screw and the gamma locking nail. J Bone Joint Surg Br, 1993;75:789-793.
31. Sernbo I, Johnell O, Gentz CF, Nilsson JA. Unstable intertrochanteric fractures of the hip. Treatment with Ender pins compared with a compression hip-screw. J Bone Joint Surg Am, 1988;70:1297-1303.
32. Sommers MB, Roth C, Hall H, et al. A laboratory model to evaluate cutout resistance of implants for pertrochanteric fracture fixation. J Orthop Trauma, 2004;18:361-368.
33. Utrilla AL, Reig JS, Muñoz FM, Tufanisco CB. Trochanteric gamma nail and compression hip screw for trochanteric fractures: a randomized, prospective, comparative study in 210 elderly patients with a new design of the gamma nail. J Orthop Trauma, 2005;19:229-233.
34. Wu CC, Shih CH, Lee MY, Tai CL. Biomechanical analysis of location of lag screw of a dynamic hip screw in treatment of unstable intertrochanteric fracture. J Trauma, 1996;41:699-702.
35. Yoshimine F, Latta LL, Milne EL. Sliding characteristics of compression hip screws in the intertrochanteric fracture: a clinical study. J Orthop Trauma, 1993;7:348-353.

Fig. 1

(A) Anteroposterior radiograph and (B) 3-D computed tomography demonstrating typical high pertrochanteric fracture (HPF). (C) Schematic drawing of HPF. Fractures that occur within the dotted line, regardless of lesser trochanteric fragment, are regarded as HPFs.

Fig. 2

The change in the neck-shaft angle on (A) anteroposterior or (B) lateral radiograph during the early follow-up period means varus or retroversion collapse with the change of the lag screw position, respectively, which causes reduction loss and lag screw cut-out.

Fig. 3

(A) Pre-operative radiograph and 3-D computed tomography of a 77-year-old female show a high pertrochanteric fracture with a lesser trochanteric fragment and the comminution of the greater trochanter tip classified as AO type A2.1.

(B) Post-operative radiographs show anatomical reduction with an appropriate lag screw position after hip nailing with a Gamma 3 nail.

(C) Post-operative 6-week radiographs show the rotation of the femoral head.

(D) Post-operative 3-month radiographs show the collapse of the proximal fragment due to the rotation of the femoral head.

(E) Post-operative 6-month radiographs finally show the varus collapse of the proximal fragment with the change of lag screw position within the femoral head.

Table 1

Demographics of 14 patients

BMD: Bone mineral density, PFNA: Proximal femoral nail antirotation, ITST: Intertrochanteric-subtrochanteric nail.

Table 2

The peri-operative radiologic data of 14 patients with fixation failure

GT: Greater trochanter, HPF: High pertrochanteric fracture, LS: Lag screw, FH: Femoral head, AP: Anteroposterior, M: Medial to trochanteric tip, T: Trochanteric tip, L: Lateral to trochanteric tip.

Table 3

The radiologic results of 14 patients at time of fixation failure

LS: Lag screw, BHA: Bipolar hemiarthroplasty, THA: Total hip arthroplasty.
