- HOME > J Musculoskelet Trauma > Volume 32(2); 2019 > Article
- Case Report Progressive Brachial Plexus Palsy after Fixation of Clavicle Shaft Nonunion: A Case Report
- Hong Ki Jin, Ki Bong Park, Hyung Lae Cho, Jung Il Kang, Wan Seok Lee
-
Journal of Musculoskeletal Trauma 2019;32(2):97-101.
DOI: https://doi.org/10.12671/jkfs.2019.32.2.97
Published online: April 30, 2019
Department of Orthopedic Surgery, Good Samsun Hospital, Busan, Korea. hongiroom@naver.com
- 144 Views
- 0 Download
- 0 Crossref
- 0 Scopus
Abstract
The brachial plexus palsy is a rare complication of a clavicle fracture, occurring in 0.5% to 9.0% of cases. This condition is caused by excessive callus formation, which can be recovered by a spur resection and surgical fixation. In contrast, only seven cases have been reported after surgical reduction and fixation. A case of progressive brachial plexus palsy was observed after fixation of the displaced nonunion of a clavicle fracture. The symptom were improved after removing the implant.
J Korean Fract Soc. 2019 Apr;32(2):97-101. Korean.
Published online Apr 16, 2019.
https://doi.org/10.12671/jkfs.2019.32.2.97
Published online Apr 16, 2019.
https://doi.org/10.12671/jkfs.2019.32.2.97
Copyright © 2019 The Korean Fracture Society. All rights reserved.
Case Report
Progressive Brachial Plexus Palsy after Fixation of Clavicle Shaft Nonunion: A Case Report
Hong-Ki Jin
, M.D.,
Ki Bong Park, M.D.,
Hyung Lae Cho, M.D.,
Jung-Il Kang, M.D.
and Wan Seok Lee, M.D.
, M.D.,
Ki Bong Park, M.D.,
Hyung Lae Cho, M.D.,
Jung-Il Kang, M.D.
and Wan Seok Lee, M.D.
Abstract
The brachial plexus palsy is a rare complication of a clavicle fracture, occurring in 0.5% to 9.0% of cases. This condition is caused by excessive callus formation, which can be recovered by a spur resection and surgical fixation. In contrast, only seven cases have been reported after surgical reduction and fixation. A case of progressive brachial plexus palsy was observed after fixation of the displaced nonunion of a clavicle fracture. The symptom were improved after removing the implant.
Keywords
Clavicle fracture, Nonunion, Brachial plexus neuropathy, Thoracic outlet syndrome
Figures
Fig. 1
Distance from the 1st rib to the clavicle of the non-union side changed from 41.2 mm (A, preoperative) to 28.5 mm (B, postoperative). After implant removal (C) displacement recurred and the distance increased to 42.1 mm. Three-dimensional computed tomography shows that bony spur alone coraco-clavicular ligament (A) was completely removed (B, C). The level of the scapular spine migrated 24.6 mm upward after fixation (B) and returned to the preoperative state after implant removal (C).
Fig. 2
(A) Postoperative thoracic outlet magnetic resonance imaging (MRI) shows normal brachial plexus continuity witout hematoma. (B) Cervical spine MRI shows cervical disc degeneration without both disc herniation or spinal cord lesion.
Fig. 3
(A) Normal contour of the clavicle was recovered after a strut bone graft and fixation. (B) A 16 mm step off of the medial clavicle fragment occurred immediately after removing the plate.
Notes
Financial support:None.
Conflict of interests:None.
References
-
Rumball KM, Da Silva VF, Preston DN, Carruthers CC. Brachial-plexus injury after clavicular fracture: case report and literature review. Can J Surg 1991;34:264–266.
-
-
Hill JM, McGuire MH, Crosby LA. Closed treatment of displaced middle-third fractures of the clavicle gives poor results. J Bone Joint Surg Br 1997;79:537–539.
-
-
Rosati M, Andreani L, Poggetti A, Zampa V, Parchi P, Lisanti M. Progressive brachial plexus palsy after osteosynthesis of an inveterate clavicular fracture. J Orthop Case Rep 2013;3:18–21.
-
-
Woltz S, Krijnen P, Schipper IB. Plate fixation versus nonoperative treatment for displaced midshaft clavicular fractures: a meta-analysis of randomized controlled trials. J Bone Joint Surg Am 2017;99:1051–1057.
-
-
Song SW, Lee HS, Woo YK, Rhee SK, Kim YY. Treatment of clavide fracture: operative vs non-operative. J Korean Soc Fract 2000;13:544–549.
-
-
Clitherow HDS, Bain GI. Major neurovascular complications of clavicle fracture surgery. Shoulder Elbow 2015;7:3–12.
-
-
Lee WS, Chung WY, Jeon TS, Kim YS, Kim NH. Delayed brachial plexus palsy due to clavicular fracture. J Korean Soc Fract 2003;16:230–234.
-
-
Tanaka Y, Aoki M, Izumi T, Fujimiya M, Yamashita T, Imai T. Measurement of subclavicular pressure on the subclavian artery and brachial plexus in the costoclavicular space during provocative positioning for thoracic outlet syndrome. J Orthop Sci 2010;15:118–124.
-
-
Connolly JF, Dehne R. Nonunion of the clavicle and thoracic outlet syndrome. J Trauma 1989;29:1127–1132.discussion 1132-1133.
-
-
Jeyaseelan L, Singh VK, Ghosh S, Sinisi M, Fox M. Iatropathic brachial plexus injury: a complication of delayed fixation of clavicle fractures. Bone Joint J 2013;95:106–110.
-
