Cannulated Screw and Wire Fixation with Predrilling for Olecranon Osteotomy in Intra-articular Comminuted Distal Humerus Fractures: Soo-Hong Han, M.D., Ph.D., Ho-Jae Lee, M.D., Woo-Hyun Kim, M.D., Yong-Gil Jo, M.D., Won-Tae Song, M.D.; Journal of the Korean Fracture Society 2015;28(2):118-124.
DOI: https://doi.org/10.12671/jkfs.2015.28.2.118
Published online: April 21, 2015

Department of Orthopaedic Surgery, CHA Bundang Medical Center, CHA University, Seongnam, Korea.

Address reprint requests to: Soo-Hong Han, M.D., Ph.D. Department of Orthopaedic Surgery, CHA Bundang Medical Center, CHA University, 59 Yatap-ro, Bundang-gu, Seongnam 463-712, Korea. Tel: 82-31-780-6074, Fax: 82-31-708-3578, hsoohong@cha.ac.kr

• Received: December 19, 2014 • Revised: February 18, 2015 • Accepted: March 6, 2015

This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

51 Views
1 Download

prev next

Full Article

Download PDF

Abstract
NOTES
REFERENCES

Abstract

Purpose
The olecranon osteotomy in intra-articular comminuted distal humerus fractures is a suggested technique for excellent exposure of articular fractures. However, complications including delayed union, nonunion of osteotomy site have been reported. Authors have applied predrilling for cannulated screw before osteotomy for achievement of rapid and accurate reposition of separation part and added wire fixation for secure stability. The purpose of this study is to evaluate the efficacy of this fixation procedure following the olecranon osteotomy during the internal fixation of intra-articular fracture of the distal humerus.
Materials and Methods
This study retrospectively analyzed 14 cases (9 women and 5 men) of intra-articular distal humerus fractures in which the olecranon osteotomy was applied. The mean age of patients was 53.4 years (range, 25 to 83 years), and the average follow-up period was 15.9 months. Eleven cases were classified as AO 13-C3, and the other 3 cases were AO 13-C2. Reduction accuracy, union period of osteotomy site on follow-up radiographs and postoperative complications related to olecranon osteotomy were evaluated.
Results
All osteotomized parts showed no position change and solid union with normal alignment at the last follow-up. The mean period of bony union was 3.5 months (range, 2 to 5 months). There were no complications related to olecranon osteotomy except one case of non-displaced fracture of the proximal ulnar shaft at the level of cannulated screw tip caused by forceful passive physical therapy. It was managed by conservative treatment without further problem.
Conclusion
Predrilled cannulated screw and wire fixation following the olecranon osteotomy during internal fixation of intra-articular comminuted distal humerus fractures showed satisfactory results in the union of osteotomy site and it could be a recommendable procedure when fractures require olecranon osteotomy.
Key words: Intra-articular fractures, Osteotomy, Olecranon process, Humerus, Elbow

None.

REFERENCES

1. Cassebaum WH. Operative treatment of T and Y fractures of the lower end of the humerus. Am J Surg, 1952;83:265-270.Article
2. Cassebaum WH. Open reduction of T & Y fractures of the lower end of the humerus. J Trauma, 1969;9:915-925.Article
3. Wilkinson JM, Stanley D. Posterior surgical approaches to the elbow: a comparative anatomic study. J Shoulder Elbow Surg, 2001;10:380-382.Article
4. Illical EM, Farrell DJ, Siska PA, Evans AR, Gruen GS, Tarkin IS. Comparison of outcomes after triceps split versus sparing surgery for extra-articular distal humerus fractures. Injury, 2014;45:1545-1548.Article
5. Coles CP, Barei DP, Nork SE, Taitsman LA, Hanel DP, Bradford Henley M. The olecranon osteotomy: a six-year experience in the treatment of intraarticular fractures of the distal humerus. J Orthop Trauma, 2006;20:164-171.Article
6. Gainor BJ, Moussa F, Schott T. Healing rate of transverse osteotomies of the olecranon used in reconstruction of distal humerus fractures. J South Orthop Assoc, 1995;4:263-268.
7. Pajarinen J, Björkenheim JM. Operative treatment of type C intercondylar fractures of the distal humerus: results after a mean follow-up of 2 years in a series of 18 patients. J Shoulder Elbow Surg, 2002;11:48-52.Article PubMed
8. Ring D, Gulotta L, Chin K, Jupiter JB. Olecranon osteotomy for exposure of fractures and nonunions of the distal humerus. J Orthop Trauma, 2004;18:446-449.Article PubMed
9. Gebert C, Hillmann A, Schwappach A, et al. Free vascularized fibular grafting for reconstruction after tumor resection in the upper extremity. J Surg Oncol, 2006;94:114-127.Article
10. Gupta R. Intercondylar fractures of the distal humerus in adults. Injury, 1996;27:569-572.Article
11. Gupta R, Khanchandani P. Intercondylar fractures of the distal humerus in adults: a critical analysis of 55 cases. Injury, 2002;33:511-515.Article
12. Wang AA, Mara M, Hutchinson DT. The proximal ulna: An anatomic study with relevance to olecranon osteotomy and fracture fixation. J Shoulder Elbow Surg, 2003;12:293-296.Article
13. Henley MB. Intra-articular distal humeral fractures in adults. Orthop Clin North Am, 1987;18:11-23.Article PubMed
14. Henley MB, Bone LB, Parker B. Operative management of intra-articular fractures of the distal humerus. J Orthop Trauma, 1987;1:24-35.Article
15. Hutchinson DT, Horwitz DS, Ha G, Thomas CW, Bachus KN. Cyclic loading of olecranon fracture fixation constructs. J Bone Joint Surg Am, 2003;85:831-837.Article PubMed
16. Ahmed AR, Sweed T, Wanas A. The role of cancellous screw with tension band fixation in the treatment of displaced olecranon fractures, a comparative study. Eur J Orthop Surg Traumatol, 2008;18:571-576.Article PDF
17. Pollock JW, Athwal GS, Steinmann SP. Surgical exposures for distal humerus fractures: a review. Clin Anat, 2008;21:757-768.Article PubMed

Fig. 1

Operative techniques of olecranon osteotomy. (A) Midline incision with curve over the olecranon. (B) Predrilling for cannulated screw fixation after guide pin insertion. (C) Distally oriented chevron osteotomy with a predrilled hole (arrow). (D) Stabilization of fracture. (E) Reduction of osteotomized olecranon with insertion of predrilled guide pin. (F) Fixation with partially threaded 7.0 mm cannulated screw and a washer. (G) Wiring in a figure 8 pattern.

Fig. 2

Postoperative radiographs. (A) Antero-posterior view. (B) Lateral view.

Fig. 3

(A) Undisplaced ulnar shaft fracture is seen adjacent to the screw tip. (B) Fracture is healed after conservative treatment.

Table 1

Summary of Cases
